One New Aftermarket Replacement B/5L Section Industrial V-Belt, 5/8" x 29"

This B26/5L290 fractional horsepower (FHP) V-belt is a dual-designation classical drive belt used across a wide range of power transmission applications, including agricultural machinery, HVAC systems, fans, compressors, pumps, small engines, and outdoor power equipment. The wrapped polyester cord construction provides heat and oil resistance, static conductivity, and long service life across standard sheave-groove drives.

Specifications

• Belt Section: B / 5L (dual designation)
• Top Width: 5/8" (21/32")
• Outside Length: 29"
• Belt Depth / Thickness: 13/32"
• Reinforcing Cord: Polyester
• Edge Construction: Wrapped
• V-Belt Type: Fractional Horsepower (FHP) / Classical
• Minimum Pulley Pitch Diameter: 3-1/2"
• Resistance: Heat-resistant, oil-resistant, static-conductive

Compatible Applications

General Industrial and Agricultural Use: HVAC systems, fans, compressors, pumps, small engines, agricultural machinery, outdoor power equipment, and general-purpose light-duty belt drives.

Replaces Part Number(s):

5L290, B26

New aftermarket replacement part - not remanufactured, not used.
