A-M131151-AI Belt, Secondary Deck Drive Made With Aramid

A-M131151-AI Belt, Secondary Deck Drive Made With Aramid

AIC Replacement Parts


**TO VIEW PRICE**

LOGIN or REGISTER


One New Aftermarket Replacement Secondary Deck Drive Belt for Zero-Turn Mowers, Riding Mowers, and Lawn Tractors

This heavy-duty secondary deck drive belt transmits power from the engine to the mower deck cutting system. Built Made With Aramid (Made With Kevlar) cord construction for superior tensile strength, heat resistance, and extended service life. Replaces OEM part number M131151 and a wide range of cross-references across multiple brands. A Section (4L) V-belt profile, 1/2" wide x 73" outside circumference.

Specifications

  • Belt Type: A Section / 4L Classic V-Belt
  • Top Width: 1/2"
  • Outside Circumference (OC Length): 73"
  • Inside Circumference: 71"
  • Depth: 5/16"
  • Material: Made With Aramid (Made With Kevlar) Cord Construction
  • Application: Secondary Deck Drive

Compatible Models

Simplicity: 1842GV, 1842HV, BROADMOOR 2691337-00, BROADMOOR 2691178-00, PRESTIGE 2691016, PRESTIGE 2691016-01, CORONET 2690800, RE200 2690801-00, RE200 2691019-00, WRANGLER, WRANGLER SL125, RT1330 2690172, RT1330 2690173, RT1330 2690649, RT1330E 2690249, RT1330E 2690250, 1693229, 1693230, 1693231, 1693232, 1693233, 1693234, 1693235, 1693236, 1693286, 1693288, 1693296, 1693298, 1693300, 1693302, 1693467, 1693471, 1693473, 1693475, 1693477, 1694079, 1694082, 1694083, 1694084, 1694088

Snapper / Snapper Pro: JAZEE SR205, JAZEE SR210, JAZEE SR215, JAZEE SR225, JAZEE SR355, JAZEE SR360, JAZEE SR365, JAZEE SR375, JAYZEE 2007-2008, STOUT, STOUT MP, 935005, 935009, 935011, 935013, 935014, 935015, 935019, 935020, 935024, 935025, 935026, 935027, 935028, 935029, 935030, 935031, 936006, 936008, 936009, 936010, 936011, 936012, 990883, 267, 269, 1106

Hustler: FASTRAK, FASTRAK SD

Scag: TURF TIGER, CHARGER 1035, CHARGER 1040, CHARGER 1045, CHARGER 1050, CHARGER 1055

Country Clipper: GC-CS, GC-3B, GC-STC-V, GC-STC-CS61, GC-STC-61, GC-STC-CSV, GC-STT-52

Fits Craftsman (Sears): 107.277700 ZT7000, 107.277740 ZT7000, 107.277741 ZTS7500

MTD / Fits Cub Cadet: 4-36523, 7-40113

Big Dog: 4-36523

Replaces Part Number(s):

M131151, 954-0344, 754-0344, 706577, 07216100, 1726471SM, 1726471, 1651201, 482379, 604933, D3524, A71K, 4L730

Aftermarket Interchange Numbers

Also cross-references: Ariens 07216100 / 072158 / 044759, Snapper 22252 / 7022252 / 79776 / 1719746, Simplicity 119044 / 1602157 / 1632157 / 1651201 / 174687, Sears/Fits Craftsman STD304730, Gates 6873, Goodyear 84730, Fits Stens 148-073, MetalCraft 482379, Lawn-Boy 706577, Noma 305698, Gravely 32322 / 43775, Dixon 4949, Fits Napa 4L730W

New aftermarket replacement part - not remanufactured, not used.

Models This Part Fits:

1693475, 107.277740 ZT7000, GC-STT-52, 935025, 107.277700 ZT7000, GC-3B, 936010, 935020, 267, JAZEE SR215, 1693236, STOUT MP, CHARGER 1035, CHARGER 1050, JAZEE SR365, 936006, 1693232, CHARGER 1040, 1693302, TURF TIGER, 1693230, 935028, 935026, 935009, 2691019-00 RE200, 269, 1693296, 935015, 936012, 1693298, 1693231, JAZEE SR225, 1842HV, 2691178-00 BROADMOOR, 1842GV, WRANGLER, JAZEE SR355, 1693229, 935027, 2690801-00 RE200, 990883, JAZEE SR205, 935014, 1693471, 935030, 1694083, 935013, WRANGLER SL125, 1693288, 935005, 2690249 RT1330E, 1693234, 935019, GC-CS, GC-STC-CSV, 2690172 RT1330, GC-STC-61, 936009, JAZEE SR375, JAYZEE 2007-2008, FASTRAK, 1693477, GC-STC-CS61, GC-STC-V, 1693235, 1694079, 1694088, 935024, JAZEE SR210, 2691337-00 BROADMOOR, FASTRAK SD, 935031, 4-36523, CHARGER 1055, 1694084, 107.277741 ZTS7500, 2690250 RT1330E, 2690173 RT1330, 1693467, 936008, 7-40113, CHARGER 1045, 1106, STOUT, JAZEE SR360, 1693286, 935011, 935029, 1693300, 2690800 CORONET, 1693473, 2691016 PRESTIGE, 2690649 RT1330, 1693233, 2691016-01 PRESTIGE, 1694082, 936011

Additional Information:

Dim A (1) 1/2" x 73" Depth 5/16" OC Length 1/2" x 73" Top Width 1/2" Type A Section Made with Aramid Cord Material HD Drive Belt

Reference Numbers:

754-0344,954-0344, D3524, A71K, 4L730, M131151, 1726471SM, 1726471, 1651201, 706577, 1726471SM, 07216100, 604933, 482379, 954-0344, 754-0344
