84214740 V-Belt A102 4L1040 1/2 x 104 in Fits New Holland LS25 LS45 LS55 GT20
84214740 V-Belt A102 4L1040 1/2 x 104 in Fits New Holland LS25 LS45 LS55 GT20
AIC Replacement Parts - FEDEX2DAY
**TO VIEW PRICE**
LOGIN or REGISTER
This is a new aftermarket A section V-belt, replacing part number 84214740. It is not an OEM part.
This is a one half inch top width belt with a polyester cord and a wrapped cover. The size is A102, also written 4L1040, which is about one hundred four inch outside. The length the maker publishes for this belt is about one hundred three inch, so measure your old belt end to end rather than ordering by model alone.
These tractors use two belts. The LS yard tractors also use a longer belt, part number 84214746, at about one hundred forty three inch. The two are not interchangeable, so if your belt measures about one hundred forty three inch you need that belt, not this one.
Made to fit New Holland LS25, LS35, LS45 and LS55 yard tractors and the GT18, GT20, GT20A, GT22 and GT22A garden tractors, built about 1994 through 2007. It replaces 84214740 and TR94D2501.
This is the one half inch A section belt. It is not the wider five eighths inch blade drive deck belt. It is also the A102 length, not the shorter A101, also written 4L1030, or the longer A103, also written 4L1050, so match the one half inch width and the length before ordering.
This is a one half inch top width belt with a polyester cord and a wrapped cover. The size is A102, also written 4L1040, which is about one hundred four inch outside. The length the maker publishes for this belt is about one hundred three inch, so measure your old belt end to end rather than ordering by model alone.
These tractors use two belts. The LS yard tractors also use a longer belt, part number 84214746, at about one hundred forty three inch. The two are not interchangeable, so if your belt measures about one hundred forty three inch you need that belt, not this one.
Made to fit New Holland LS25, LS35, LS45 and LS55 yard tractors and the GT18, GT20, GT20A, GT22 and GT22A garden tractors, built about 1994 through 2007. It replaces 84214740 and TR94D2501.
This is the one half inch A section belt. It is not the wider five eighths inch blade drive deck belt. It is also the A102 length, not the shorter A101, also written 4L1030, or the longer A103, also written 4L1050, so match the one half inch width and the length before ordering.
Models This Part Fits:
Additional Information:
1/2" x 104" A Section Polyester Cord Color Black Depth 5/16" Length 104" Material Polyester Cord OC Length 1/2" X 104" Thickness .315" Top Width 1/2" Type A-Section Width 1/2" Replacement BeltReference Numbers:
4L1040,A102,A102/4L1040,A102DC,AP102, 84214740Makes This Part Fits:
