One New Aftermarket Replacement Starter Solenoid Switch Fits Case / Fits Case IH, David Brown, and Fits International Harvester Tractors

This 12-volt starter solenoid switch mounts directly to Fits Lucas-type starters via two studs through the drive end (DE) housing and serves as the critical electrical relay between the ignition circuit and the starter motor. Featuring four copper-contact terminals and an intermittent duty cycle rating, it is designed as a direct replacement Fits Lucas M45G (starter 26278-H) and Fits Lucas 2M113 (starter 27413-A) applications commonly found on British-built agricultural tractors.

Specifications

• Voltage: 12V
• Terminals: 4
• Contact Material: Copper
• Duty Cycle: Intermittent
• Mounting: 2 studs through DE (Drive End) Housing
• Application: Fits Lucas-type starters (M45G, 2M113)

Compatible Models

Fits Case / Fits Case IH Tractors: 1190, 1194, 1290, 1294, 1390, 1394, 1490, 1494

David Brown Tractors: 770, 780, 880, 885, 885N, 990, 995, 996, 1200, 1210, 1212, 1290, 1390, 1490

Fits International Harvester Tractors: B275, B276, B354, B364, B414, B434, 354, 364, 374, 384, 434, 444

Fits Massey Ferguson Tractors: 135 UK, 154-4, 240 (s/n N01001-A20286 and earlier), 254-4, 360, 364, 364S (s/n D03066 and earlier), 885, 1290, 1294, 1390, 1394, 1490, 1494

Fits Allis-Chalmers Tractors: ED40, 160

Fits JCB Industrial: 406

Replaces Part Number(s):

K963825, A48240, SL-148

Aftermarket Interchange Numbers

VPF2205, 3475771M91, 1042667M91, 1054058M91, 1632988M91, 1890038M1, 1893614M91, 3111040R91, 6680-8819, 25604, SSLU-842, TXB162, TOB109, TOB113, TOB121, TOB128, TOB134, TOB149, TOB162, TPB107, TPB109, TXB162, ZM612, SLU6012, 10-LU298, Fits Lucas: 76755, 76763, 76786, 76796, 76800, 76803, 76804, 76815, 76816, 76820, 76821, 76823, 76824, 76826, 76827, 76837, 76850, 76852, 76855, 76871, 76885, 76891, 76892, 76894, 76895, 76896, 76897, 76899, 76902, 76908, 76940, 76961, 76983, 77034, 77035, 77058, 77157, 77160

New aftermarket replacement part - not remanufactured, not used.
