One New Aftermarket Replacement Transmission Oil Filter for Gravely Pro-Master Zero-Turn and Hydraulic-Lift Mowers

This aftermarket replacement transmission oil filter fits the Gravely Pro-Master (PM) series commercial zero-turn and hydraulic-lift lawn mowers. It services the hydrostatic transmission and hydraulic system, maintaining clean fluid flow through the transaxle and protecting pump and motor components from wear. The filter features a built-in bypass valve and 10-micron filtration media.

Specifications

• Filtration: 10 microns
• Thread Size: 1"-12
• Housing OD: 3-3/4"
• Mounting Seal OD: 2-3/4"
• Housing Height: 5-1/4"
• Bypass Pressure Relief: 8-11 PSI
• Anti-Drain Valve: No

Compatible Models

Gravely Pro-Master Series: PM252H, PM252Z, PM260H, PM260Z, PM272H, PM272Z

Replaces Part Number(s):

03931900, 0931900, 09414200

Aftermarket Interchange Numbers

Fits Allis Chalmers 71321111, Fits Bobcat 6515541, Fits Case H311647, Fits Case S62427, Fits Caterpillar 665934, Fits Caterpillar 773492, Clark Equipment 6541193, Fits Cub Cadet 723-0405, Cushman 834702, Ditch Witch 155-910, Encore 453058, Gehl 48959, Grove 7437000192, Jacobsen 118017, Fits John Deere AT38431, MTD 723-0405, Fits New Holland 86546624, Scag 48758, Skyjack 108628, Snapper Pro 5021357X1, Fits Toro 23-9740, Fits Toro 54-0110, Vermeer 2683001, Vermeer 79703001

New aftermarket replacement part - not remanufactured, not used.
