One New Aftermarket Replacement Deck Belt for Toro, Simplicity, Bolens, MTD, Cub Cadet, Ariens, Gravely and More
This A-section classical V-belt is a direct aftermarket replacement for the mower deck drive system on a wide range of lawn tractors and zero-turn mowers. Sized at 1/2" x 130", it fits the 44" cutting deck on Toro XL Series lawn tractors and crosses to MTD, Cub Cadet, Simplicity, Bolens, Ariens, and Gravely applications using the same belt specification. Also cross-references as a standard A128 / 4L1300 industrial V-belt.
Specifications
- Type: A-Section Classical V-Belt
- Top Width: 1/2"
- Length (OC): 130"
- Depth: 5/16"
- Thickness: 0.315"
- Material: Polyester Cord
Compatible Models
Toro XL Series (44" Deck): 71212, 71228, 77106, 79105 (44-in. Recycler Mower), 79106 (44-in. Side Discharge), 79107 (44-in. Side Discharge, XL Series, 2000), 79108 (44-in. Recycler, XL Series, 2000), 17-44HXL and XL Series 1996-2003
MTD / Cub Cadet Zero-Turn: ZTT-1850, ZTT-2150, 13AU624H401, 13AD624G401
Ariens / Gravely Zero-Turn: ZTT-1850, ZTT-2150, Zoom 42", 915141, 915142, 915148, 915155, 915159, 915170, 915171, 915172, 915175, 915176, 915203, 915207, 915213, 915220, F2, F3, K2, 71212
Simplicity: 1716959 application (verify deck size and belt profile before ordering -- see note below)
Bolens / Yard Man: 171865 application
Also fits: White Outdoor, Allis Chalmers, Gleaner compatible applications using A128 / 4L1300 belt specification
Note: The Simplicity OEM part 1716959SM is cataloged by Simplicity as a Double-V (hexagonal) belt for 60" Legacy-series decks. This aftermarket belt is a single A-section V-belt (A128). Verify your deck size and belt profile before ordering for Simplicity applications.
Replaces Part Number(s):
93-3884, 933884, 954-0491, 754-0491, A128, B1A128, 4L1300, 3X633, 300-255, 300255, 71190749, 07200523, 1718653
Aftermarket Interchange Numbers
A&I Products: A-A128, A-A128-A | Standard industrial designation: A128 / 4L1300
New aftermarket replacement part - not remanufactured, not used.
Models This Part Fits:
915142, 13AU624H401, 13AD624G401, F3, K2, 79107, ZTT-2150, 915172, 77106, 915207, 915155, 915175, 915213, 915170, 915203, 915148, Zoom 42", 71228, ZTT-1850, F2, 79108, 79106, 915141, 915171, 915159, 915220, 71212, 915176, 79105Additional Information:
1/2" x 130" A Section Polyester Cord Depth 5/16" Length 130" Material Polyester Cord OC Length 1/2" X 130" Thickness .315" Top Width 1/2" Type A-Section Width 1/2" Deck BeltReference Numbers:
954-0491, 754-0491, 4L1300, A128, 300-255, 300255,, 3X633, B1A128, 1718653, 93-3884, 933884, 71190749, 07200523, 954-0491, 754-0491, 3X633Makes This Part Fits:
