One New Aftermarket Replacement PTO Conversion Shaft Assembly Fits Ford and Fits Massey Ferguson Tractors

This PTO conversion shaft assembly upgrades the original 1-1/8" (10-spline) PTO output to the modern 1-3/8" (6-spline) standard, making it compatible with today's PTO-driven implements. The assembly comes fully pre-assembled and Fits Ford N-Series tractors (1939-1952) as well as early Fits Massey Ferguson (Fits Ferguson) models that share the same drivetrain architecture.

Specifications

• Shaft Length: 30-7/8"
• Shaft Diameter: 1-3/8"
• Splines: 6
• Converts from: 1-1/8" to 1-3/8" PTO output

Kit Includes

• PTO Housing
• Collar with Set Pin
• Snap Ring
• Front PTO Bearing
• Front PTO Sleeve
• PTO Seal
• All components pre-assembled

Note: Does not include PTO housing gasket or PTO cap. For shaft only (without housing assembly) use part 186970. For 1-1/8" shaft use part 134460.

Compatible Models

Fits Ford (1939-1952): 2N, 8N, 9N

Fits Massey Ferguson / Fits Ferguson: TE20, TEA20, TO20, TO30

Replaces Part Number(s):

9N70038, 9N700-38, 9N70038S, 9N70138, 9N71038, 18116938, 181169M91, 18117338, 181173M1, 181773M1

Aftermarket Interchange Numbers

9N710B, 48A77, NAA700-38, NAA70038, A-9N70038, 1112-0009, VPH4000, VPH4001, R3585

New aftermarket replacement part - not remanufactured, not used.
